Architectural Design

Visualize your completed project with site plan assistance service.
Browse our Project Gallery to view recently completed projects that will show you a variety of architectural designs.
Your local Authorized Distributor – along with our design specialists – can help you plan your car wash from top to bottom. Two affordable packages are available, depending on your needs.

THE BASIC PACKAGE

Floor heat drawings
Complete equipment room plans
Equipment layout with schedules & notes
Underground conduit plans
Conceptual site plan (based on owner providing a plot plan and choosing a prototype footprint plan from our library)

COMPLETE DESIGN PACKAGE

Complete set of construction documents
Schedules, notes, and details
M/P/E layouts complete with fixtures & schedules
Plans, elevations, section finishes, & details
Conceptual site plan (based on owner providing a plot plan and choosing a prototype footprint plan from our library)

CONSTRUCTION

Construction estimates should include the building, excavating and paving, plumbing, concrete, electrical (including light fixtures), permit fees, equipment, and the equipment installation. You should also plan on an allowance for signs, landscaping, security, and include a dollar amount for miscellaneous expenses. Construction and equipment costs vary, depending on the type of building and number of bays you propose to build.
Contact us today to discuss with our experienced car wash professionals regarding design packages or for local assistance in developing a professional car care center.
